Scorpio Micro


Hver gang vi møtes
Hver gang vi møtes

The Micro Scorpio Head is the smallest member of our family, designed to fill a blank in the market to offer a light and compact head with a very good quality of movements and possibilities.
The head weights 6kg with a payload of 12kgs/27lbs with the smallest configuration or up to 25kgs/56lbs when mounting the cage and as per its modular design with the possibility to make it bigger, smaller, work over-slung, under-slung, inside position, outside position, centre position, offset position and many more.


Features

  • Compact two axes remote head for video and film cameras.
  • The Micro Scorpio Head can be positioned in overslung and underslung mode.
  • Mounts avaliable: Mitchell mount, tripod mount and 28 Spigot to use on a normal light stand
  • Micro Scorpio Head can be controlled from up to 500 meters by cable serie RS485 or by wireless half-duplex microwave 2,4 Hz.
  • All axes (Pan and Tilt, Focus, Iris and Zoom using the Scorpio Focus) are programable and repeatable.
  • Programmable limits, damping and speed adjustment for all axes available.Technical specifications

Spesification:

Weight
6kg/13,2lb
Max. payload
12 kg / 26,45 lb
Max. payload with cage
25 kg / 56 lb
Max. speed
2,4 s/rev
Power from battery or power supply
from 24V to 35V

Connection for Scorpio Focus and others lens control systems
